Using both QKD and PQC

FortiOS supports configuring Quantum Key Distribution (QKD) and Post-Quantum Cryptography (PQC). This allows you to mix keys from QKD, PQC, and traditional Diffie-Hellman (DH) key exchange, ensuring robust security. By combining different types of keys, users can achieve maximum resilience against potential threats.

This feature can be used in environments handling highly sensitive data, necessitating the highest level of security. For example, a financial institution might use this feature in its network infrastructure to secure communications between different system components. This ensures that even if one key exchange method is compromised, the other methods will still provide secure communication.

In such a scenario, the financial institution could enable QKD for advanced quantum security, PQC for resilience against quantum threats, and DH for traditional key exchange. By combining these methods, they can tailor their security approach to meet specific needs and maximize resilience against potential threats.

Example

To configure IPsec key retrieval with a QKD and PQC keys together by CLI:

1. Configure FGT-A

   1. Configure the QKD profile:

      config vpn qkd
          edit "qkd_1"
              set server "10.1.100.9"
              set port 8989
              set id "123456"
              set peer "qkdtest"
          next
      end

   2. Configure the IPsec phase1 interface:

      config vpn ipsec phase1-interface
          edit "test_qkd"
              set interface "port9"
              set peertype any
              set net-device disable
              set proposal aes128-sha256 aes256-sha256 aes128gcm-prfsha256 aes256gcm-prfsha384 chacha20poly1305-prfsha256
              set dhgrp 21
              set addke1 1080
              set qkd require
              set qkd-hybrid require
              set qkd-profile "qkdtest"
              set remote-gw 173.1.1.1
              set psksecret **********
          next
      end

   3. Configure the IPsec phase2 interface :

      config vpn ipsec phase2-interface
          edit "test_qkd"
              set phase1name "test_qkd"
              set proposal aes128-sha1 aes256-sha1 aes128-sha256 aes256-sha256 aes128gcm aes256gcm chacha20poly1305
              set dhgrp 20 21
              set addke1 35
          next
      end

2. Configure FGT-D

   1. Configure the QKD profile:

      config vpn qkd
          edit "qkdtest"
              set server "10.1.100.9"
              set port 8989
              set id "123456"
              set peer "qkdtest"
          next
      end

   2. Configure the IPsec phase1 interface:

      config vpn ipsec phase1-interface
          edit "test_qkd"
              set interface "test_qkd"
              set peertype any
              set net-device disable
              set proposal aes128-sha256 aes256-sha256 aes128gcm-prfsha256 aes256gcm-prfsha384 chacha20poly1305-prfsha256
              set dhgrp 21
              set addke1 1080
              set qkd require
              set qkd-hybrid require
              set qkd-profile "qkdtest"
              set remote-gw 11.101.1.1
              set psksecret **********
          next
      end

   3. Configure the IPsec phase2 interface :

      config vpn ipsec phase2-interface
          edit "test_qkd"
              set phase1name "test_qkd"
              set proposal aes128-sha1 aes256-sha1 aes128-sha256 aes256-sha256 aes128gcm aes256gcm chacha20poly1305
              set dhgrp 20 21
              set addke1 35
          next
      end

To verify the configuration on FGT-A:

1. Generate traffic between PC1 and PC4.

2. Verify the IPsec phase1 interface status:

   # diagnose vpn ike gateway list
   vd: root/0
   name: test_qkd
   version: 2
   interface: port9 15
   addr: 11.101.1.1:500 -> 173.1.1.1:500
   tun_id: 173.1.1.1/::173.1.1.1
   remote_location: 0.0.0.0
   network-id: 0
   transport: UDP
   created: 1557s ago
   peer-id: 173.1.1.1
   peer-id-auth: no
   pending-queue: 0
   PPK: no
   IKE SA: created 1/18  established 1/18  time 0/2/10 ms
   IPsec SA: created 1/33  established 1/18  time 0/16/20 ms

     id/spi: 67 bc882e536cbc7f1d/ede854f1e0dc71bb
     direction: responder
     status: established 17-17s ago = 0ms
     proposal: aes128-sha256
     child: yes
     SK_ei: 4e415c84e086e980-059f1be89239ec30
     SK_er: fb14db5b3718dad4-e7f5158308ba00c0
     SK_ai: 8894937bd4e66304-a5c64941dc08d544-c7d725408247cfc4-489a292a3fb44b51
     SK_ar: 0bbf85dcd9daaa1b-1f1e04318b69aaae-befc871e40f9ab4c-0d005f0f980a3d60
     message-id sent/recv: 0/1
     QKD: yes
     PQC-KEM (IKE): yes
     PQC-KEM (all IPsec): yes
     lifetime/rekey: 86400/86112
     DPD sent/recv: 00000000/00000000
     peer-id: 173.1.1.1

3. Verify the IPsec phase2 interface status:

   # diagnose vpn tunnel list
   list all ipsec tunnel in vd 0
   ------------------------------------------------------
   name=test_qkd ver=2 serial=1 11.101.1.1:0->173.1.1.1:0 nexthop=11.101.1.2 tun_id=173.1.1.1 tun_id6=::173.1.1.1 status=up dst_mtu=1500 weight=1
   bound_if=15 real_if=15 lgwy=static/1 tun=intf mode=auto/1 encap=none/552 options[0228]=npu frag-rfc  run_state=0 role=primary accept_traffic=1 overlay_id=0

   proxyid_num=1 child_num=0 refcnt=3 ilast=1270 olast=1270 ad=/0
   stat: rxp=69 txp=70 rxb=10420 txb=5880
   dpd: mode=off
   natt: mode=none draft=0 interval=0 remote_port=0
   fec: egress=0 ingress=0
   proxyid=test_qkd proto=0 sa=1 ref=2 serial=2 auto-negotiate
     src: 0:0.0.0.0-255.255.255.255:0
     dst: 0:0.0.0.0-255.255.255.255:0
     SA:  ref=6 options=18227 type=00 soft=0 mtu=1438 expire=3297/0B replaywin=2048
          seqno=1 esn=0 replaywin_lastseq=00000000 qat=0 rekey=0 hash_search_len=1
     life: type=01 bytes=0/0 timeout=3329/3600
     dec: spi=450287b6 esp=aes key=16 42551cf97c77fb110f44574e0b33b36a
          ah=sha1 key=20 640b627fb80f4342a488349bdd35437db381640c
     enc: spi=a8a6afc3 esp=aes key=16 238c43ac7ee569c20ba5861fb8336c9a
          ah=sha1 key=20 d1226a16bfecb186148aafbce42a5da34e246afb
     dec:pkts/bytes=0/0, enc:pkts/bytes=0/0
     npu_flag=03 npu_rgwy=173.1.1.1 npu_lgwy=11.101.1.1 npu_selid=1 dec_npuid=1 enc_npuid=1

4. Verify IKE debug messages on:

   # diagnose debug application ike -1
   ...
   ike V=root:0:64555dc0381b820e/0000000000000000:70: received notify type USE_QKD
   ike V=root:0:64555dc0381b820e/0000000000000000:70: received notify type INTERMEDIATE_EXCHANGE_SUPPORTED
   ike V=root:0:64555dc0381b820e/0000000000000000:70: incoming proposal:
   ike V=root:0:64555dc0381b820e/0000000000000000:70: proposal id = 1:
   ike V=root:0:64555dc0381b820e/0000000000000000:70:   protocol = IKEv2:
   ike V=root:0:64555dc0381b820e/0000000000000000:70:      encapsulation = IKEv2/none
   ike V=root:0:64555dc0381b820e/0000000000000000:70:         type=ENCR, val=AES_CBC (key_len = 128)
   ike V=root:0:64555dc0381b820e/0000000000000000:70:         type=INTEGR, val=AUTH_HMAC_SHA2_256_128
   ike V=root:0:64555dc0381b820e/0000000000000000:70:         type=PRF, val=PRF_HMAC_SHA2_256
   ike V=root:0:64555dc0381b820e/0000000000000000:70:         type=DH_GROUP, val=ECP521.
   ike V=root:0:64555dc0381b820e/0000000000000000:70:         type=ADDKE1, val=KYBER512.
   ...
   ike V=root:0:test_qkd:70: process NAT-D
   ike V=root:0:test_qkd:70: processing notify type FRAGMENTATION_SUPPORTED
   ike V=root:0:test_qkd:70: processing notify type USE_QKD
   ike V=root:0:test_qkd:70: responder preparing SA_INIT msg
   ...
   ike V=root:0:test_qkd:70: responder received INTEREMDIATE msg
   ike V=root:0:test_qkd:70: processing KE group 1080
   ike V=root:0:test_qkd:70: KEM encapsulate okay
   ike V=root:0:test_qkd:70: responder INTERMEDIATE send
   ike V=root:0:test_qkd:70: construct KE (1080) payload
   ...
   ike V=root:0:test_qkd:73: received followup-ke request
   ike V=root:0:test_qkd:73: responder received FOLLOWUP_KE msg
   ike V=root:0:test_qkd:73: processing notify type ADDITIONAL_KEY_EXCHANGE
   ike V=root:0:test_qkd:73: received ADDKE notify link data size (len=4)
   ike V=root:0:test_qkd:73: FOLLOWUP_KE continuation for IKE SA 1d5770c3f3044565/b2cb648b2f8e064d
   ike V=root:0:test_qkd:74: KEM encapsulate okay
   ike V=root:0:test_qkd:74: responder preparing IKE SA FOLLOWUP_KE message
   ike V=root:0:test_qkd:74: construct KE grp (1080) payload
   ...
   ike V=root:0:test_qkd:74::80: QKD responder request '49d2bff4-0e61-11f0-8e8b-6bdf091987ab'
   ike V=root:0:test_qkd:74::80: QKD responder key-id '49d2bff4-0e61-11f0-8e8b-6bdf091987ab'
   ike V=root:0:test_qkd:74:80: peer proposal:
   ike V=root:0:test_qkd:74:80: TSi_0 0:0.0.0.0-255.255.255.255:0
   ike V=root:0:test_qkd:74:80: TSr_0 0:0.0.0.0-255.255.255.255:0
   ike V=root:0:test_qkd:74:test_qkd:80: comparing selectors
   ike V=root:0:test_qkd:74:test_qkd:80: matched by rfc-rule-2
   ike V=root:0:test_qkd:74:test_qkd:80: phase2 matched by subset
   ike V=root:0:test_qkd:74:test_qkd:80: accepted proposal:
   ike V=root:0:test_qkd:74:test_qkd:80: TSi_0 0:0.0.0.0-255.255.255.255:0
   ike V=root:0:test_qkd:74:test_qkd:80: TSr_0 0:0.0.0.0-255.255.255.255:0
   ike V=root:0:test_qkd:74:test_qkd:80: autokey
   ike V=root:0:test_qkd:74:test_qkd:80: incoming child SA proposal:
   ike V=root:0:test_qkd:74:test_qkd:80: proposal id = 1:
   ike V=root:0:test_qkd:74:test_qkd:80:   protocol = ESP:
   ike V=root:0:test_qkd:74:test_qkd:80:      encapsulation = TUNNEL
   ike V=root:0:test_qkd:74:test_qkd:80:         type=ENCR, val=AES_CBC (key_len = 128)
   ike V=root:0:test_qkd:74:test_qkd:80:         type=INTEGR, val=SHA
   ike V=root:0:test_qkd:74:test_qkd:80:         type=DH_GROUP, val=ECP384
   ike V=root:0:test_qkd:74:test_qkd:80:         type=DH_GROUP, val=ECP521
   ike V=root:0:test_qkd:74:test_qkd:80:         type=ESN, val=NO
   ike V=root:0:test_qkd:74:test_qkd:80:         type=ADDKE1, val=ML-KEM-512.
   ...
   ike V=root:0:test_qkd:74:test_qkd:80: ADDKE negotiated
   ...
   ike V=root:0:test_qkd:74: responder received FOLLOWUP_KE msg
   ike V=root:0:test_qkd:74: processing notify type ADDITIONAL_KEY_EXCHANGE
   ike V=root:0:test_qkd:74: received ADDKE notify link data size (len=4)
   ike V=root:0:test_qkd:74: FOLLOWUP_KE continuation for IPsec SA bc870245/c9afa6a8
   ike V=root:0:test_qkd:80: KEM encapsulate okay
   ike V=root:0:test_qkd:80: responder preparing CHILD SA FOLLOWUP_KE message
   ike V=root:0:test_qkd:80: construct KE grp (35) payload

5. Verify the statistics of QKD profile:

   # diagnose vpn ike qkd qkdtest
   ike.qkd.server.dns.addrs:
   ike.qkd.server.curl.initiator.error.request.send.count: 10
   ike.qkd.server.curl.initiator.error.request.send.last.ticks: 4295033761
   ike.qkd.server.curl.initiator.error.request.send.last.ago: 1986
   ike.qkd.server.curl.initiator.error.request.send.last.local: 2025-04-01 06:12:40 +1200
   ike.qkd.server.curl.initiator.error.request.send.last.utc: 2025-03-31 18:12:40
   ike.qkd.server.curl.initiator.error.request.send.value: 7
   ike.qkd.server.curl.inflight: now 0  max 2  total 48
   ike.qkd.server.curl.ssl.verify.count: 3952
   ike.qkd.server.curl.ssl.verify.last.ticks: 4295231030
   ike.qkd.server.curl.ssl.verify.last.ago: 13
   ike.qkd.server.curl.ssl.verify.last.local: 2025-04-01 06:45:33 +1200
   ike.qkd.server.curl.ssl.verify.last.utc: 2025-03-31 18:45:33
