Creating a virtual private cloud

  1. Assuming this is a new environment, the first step is to create the virtual private cloud (VPC). In the Alibaba Cloud web console, select Virtual Private Cloud.

  2. Click Create VPC.
  3. Configure the following settings.
  4. VPC
    Name Enter a name for the VPC.
    IPv4 CIDR Block Specify the IPv4 CIDR Block for this VPC.
    Resource Group Select the resource group for the VPC.
    VSwitch
    Name Enter a name for the VSwitch.
    Zone Select the zone of the VSwitch. In later steps, you should deploy FortiWeb-VM in the same zone.

    IPv4 CIDR Block

    Specify the IPv4 CIDR Block for this VSwitch. It should be a subnet of the VPC.
