Appendix C – ON PREMISE DEPLOYMENTS

This chapter describes how to set up the FortiEDR backend components for on-premise deployments. Before you start, make sure that on-premise deployment is the most suitable option for you.

System requirements

The following tables lists the system requirements of each backend component. Make sure that all devices, workstations, virtual machines and servers on which a FortiEDR backend component will be installed comply with those requirements.

Component

Central Manager

Aggregator¹

Threat Hunting Repository

Core²

Reputation Server

Processor

Intel or AMD x86 (64-bit)

Number of CPUs

Varies by number of seats and period of required Threat Hunting data retention. Refer to the Threat Hunting Repository CPU, Physical Memory, and Disk Space Requirements section for requirements for one month of data retention for the extensive profile.

4 for Core

2 for Core running as a Jumpbox

The following CPUs are unsupported:

E5-2440
E5-2650
E5-2660
E5-2690
E5-2699

Physical Memory

16 GB

16 GB for Core

8 GB for Core running as a Jumpbox

16 GB

Disk Space

150 GB, SSD

80 GB

250 GB SSD for Core
50 GB (non-SSD) for Core running as a Jumpbox

For a Threat Hunting license, each 1000 additional Collectors above the first 1000 require an additional 45 GB of disk space.

120 GB

ISO Image OS

Ubuntu 22.04

ESXi 7.0

Ubuntu 22.04

¹If organizations will be defined and the number of Collectors exceeds 10000, set up an additional FortiEDR Aggregator VM on the top of the initial one.

²Refer to the following guidelines to determine the number of Cores you need to set up:

Set up a separate Core for each Aggregator.
For every additional 5000 Collectors, set up at least one additional Core. The number of additional Cores required depends on the amount of Threat Hunting events data, which relates to the Data Collection profile, number of servers, etc.
You can set up a maximum of 50 Cores.

Network ports

Refer to the following image or table for the port information for communication between different components. Ensure that these ports or destination servers are not blocked by your firewall product (if one is deployed) and can be accessed by the corresponding component. You must also ensure that network ranges 10.42.x.x and 10.43.x.x are not used by any device.

Source Destination Port Purpose

Collector Aggregator 8081 Sending events, status, etc

443

Sending events, status, etc, only when a custom port is used

Core 555 Collector to Core communication without SSL

(Core 5.2.2 or later) 559 Collector to Core communication with SSL enabled

(Windows Collector 5.2.5.0052 or later) Reputation service (both on-premise and cloud)

443

Sending requests for reputation data.

Core

Aggregator

8081

Core registration

Threat Hunting Repository

9092

Kafka topic

32100, 32000, 32001, 32002

Kafka broker

Reputation service (both on-premise and cloud)

443

Sending requests for reputation data.

Aggregator

Central Manager and Threat Hunting Repository

8090

AV Signature updates

Central Manager

8091

Aggregator communication

443

Aggregator registration

Central Manager

Threat Hunting Repository

8000

“FortiEDR Connect” related

8095

Threat Hunting queries

6379

Redis MS

Syslog

(Optional) 6514

Syslog messages from Central Manager IP to syslog server via UDP/TCP/TCP SSL

SMTP

(Optional) 587

SSLv3/TLS protocol to email server

rbq.cldsrv.ensilo.com

5672

To RabbitMQ

cldsrv.ensilo.com

443

Data sent to FCS (rest over RabbitMQ)

storage.googleapis.com

oauth.googleapis.com

oauth2.googleapis.com

Localization, scheduled queries, etc

fortiav.cloud.ensilo.com

AV signatures updates

Reputation service (cloud)

443

If proxy is not enabled, on-premise reputation service requests missing hashes from the cloud reputation service via the manager nginx.

Threat Hunting Repository

Central Manager

8091

Aggregator communication

5005

“FortiEDR Connect” dedicated tunnel

443

GUI access

Central Manager and Aggregator

Communication with Central Manager and Aggregator during Threat Hunting Repository installation

Admin PC

Central Manager

443

FortiEDR console access

Reputation service (on-premise)

Central Manager

8091

If proxy is not enabled, on-premise reputation service requests missing hashes from the cloud reputation service via the manager nginx.

Reputation service (cloud)

Proxy port

If proxy is enabled, on-premise reputation service requests missing hashes from the cloud reputation service via proxy.

Machines connecting to Grafana or Kibana

Threat Hunting Repository

3000

Grafana - monitoring

5601

Kibana - logging

Machines accessing the Threat Hunting server via SSH

Central Manager

SSH access

Aggregator

Threat Hunting Repository

As a security best practice, it is recommended to update the firewall rules so that they only have a narrow opening. For example:

Only open the TCP outbound port 555 to the Core IP address.
Only open the TCP outbound port 8091 to the Central Manager IP address to be accessed by the Aggregator when the Aggregator is installed on premise while the Central Manager is in the cloud.

Threat Hunting Repository CPU, Physical Memory, and Disk Space Requirements

Number of Seats

Number of VMs (Nodes)

Number of CPUs per VM (Node)

Memory per VM (Node)

OS Disk per VM (Node)

Data Disk per VM (Node)

2000 or fewer

40 GB

100 GB, non-SSD

For Hyper-V VMs, the disk should be IDE with at least 30% of the physical disk space remaining free at all times. Do not use a Hyper-V checkpoint which consumes the entire disk size every few hours.

1500 GB SSD

4000

40 GB

2310 GB SSD

6000

41 GB

3410 GB SSD

8000

48 GB

4510 GB SSD

10000

55 GB

5610 GB SSD

12000

62 GB

6710 GB SSD

14000

69 GB

7810 GB SSD

15000

27 GB

3249 GB SSD

20000

35 GB

4318 GB SSD

25000

42 GB

5387 GB SSD

30000

47 GB

6456 GB SSD

For the Threat Hunting Repository specifications required for supporting more than 30000 Collectors, please contact Fortinet Support.
